36
Preparations
Eco setting (Power-saving mode)
The Eco setting enables the power saving feature. A long-time measurement
can be performed using batteries only.
1. Press the MENU/ENTER key to bring up the menu list screen.
2. Use the
keys to select [System (Language)] and press
the MENU/ENTER key. The system screen appears.
3. Use the keys to select [Eco Setting] and press the MENU/
ENTER key. The con rmation screen appears.
4. Use the
keys to select [YES] and press the MENU/ENTER
key. The eco setting is executed.
5. Press the START/STOP key to return to the measurement screen.
When the eco setting is executed, the setting of the item is changed automatically
as follows.
Backlight auto off 30 sec
Backlight brightness 1
OUTPUT OFF
Communication interface OFF
LCD auto off at auto store 1 min
(only when optional VX-55EX is installed)
Comparator OFF
(only when optional VX-55EX is installed)
