Store Operation
The VM-55 can store measurement data (processed data such as vibration
level and equivalent continuous level, and measurement parameters) in the
internal memory or on SD memory card.
This chapter describes how to store data in memory and how to recall data
from memory. There are three different modes of storing data, as listed below.
When the optional Extended Function Program VX-55EX is not installed,
only the manual mode can be operated.
Store names cannot be set when no SD memory card is inserted.
Important
Use SD memory cards provided by Rion. The
performance of other cards is not guaranteed
(see page 100).
Note
Prior to measurement, it is recommended rst to
format the memory card for storing data with this
unit (see page 101).
Manual
Only processed data are considered as a single data set, and an operator stores
the data set one-by-one manually.
When an operator performs store operation after a measurement, each processed
value and measurement condition will be stored with the time value.
If no SD memory card is inserted, the data will be stored in the internal memory
of the unit. If an SD memory card is inserted, the data will automatically be
stored on the card.
Internal memory capacity: max. 1000 data sets
SD memory card capacity: max. 1000 data sets per store name
