B Class Atlantic 85 Manual – First Issue, June 2017
Activity 9 - Propulsion and Auxiliary Systems
The tiller arm should be connected to the socket on the
starboard engine. You will now have emergency steering
control for the two engines.
For an outline of procedures for emergency situations on
the Atlantic 85, refer to:
Emergency Situations
EOP
Emergency steering system
Should the hydraulics fail on the steering system, the
Atlantic 85 can be set up to be steered manually. To do
this, first locate the emergency bypass lever under a
central flap just forward of the engines.
Opening the emergency bypass valve allows the free
flow of hydraulic fluid between the two sides of the
steering cylinder.
Open Position Closed position
Emergency tiller arm
The emergency tiller arm is located on the port side of the
boat near crew seat 4.
Stern
Bow
