B Class Atlantic 85 Manual – First Issue, June 2017
Activity 9 - Propulsion and Auxiliary Systems
ECU (engine control unit)
Capsize solenoid and plunger
Polyswitch box
Front cowling opening handle
Trim/tilt unit
Timing belt and cams
Oil filler
Low pressure fuel pump
Fuel filter
Rear cowling opening handle
Tell tale outlet
F115A (OE 33) front view F115A (OE 33) rear view
Engine layout (F115A/OE 33 main views)
F115 (OE 26) view
