8-32 Empennage Ballast
NOTE
Use only approved materials listed in § 20-70.
CAUTION
Altering fixed ballast can appreciably affect helicopter center of
gravity (CG). If fixed ballast information is unknown, reweigh
helicopter per § 8-22.
CAUTION
Maximum allowable empennage ballast is 3.00 lb (except Police
and E.N.G. Versions).
A. Removal
1. Refer to Figure 8-5. Remove empennage assembly, including D301-2 ballast
weights, per § 53-50.
2. Solvent-clean bare metal around and between bolt holes on horizontal stabilizer
upper and lower surfaces.
3. Apply light coat zinc-chromate or epoxy primer to bare metal surfaces. While
primer is wet, install empennage assembly per § 53-50. Topcoat hardware with
colored paint as desired.
4. Reweigh and/or calculate basic empty weight and CG per § 8-22.
5. Revise Weight and Balance Record in R66 Pilot's Operating Handbook (POH)
Section 6 to reflect ballast removal using the following data:
Item Weight
Longitudinal
Arm
Longitudinal
Moment
Lateral
Arm
Lateral
Moment
Empennage
Ballast
3.00 lb 325.44 in. 976.32 in.-lb 4.45 in. 13.35 in.-lb
B. Installation
1. Refer to Figure 8-5. Remove empennage assembly per § 53-50.
2. Solvent-clean bare metal around and between bolt holes on horizontal stabilizer
upper and lower surfaces.
3. Temporarily install D301-2 weights per IPC Figure 8-1. Torque bolts per § 20-32.
4. Trace outline of weights onto horizontal stabilizer upper and lower surfaces using
felt-tip, non-permanent marker or tape. Remove weights.
JUL 2020 Chapter 8 Weight and Balance Page 8.13
