71-22 Cage Assembly
A. Removal
1. Remove tail rotor drive fan shaft per § 65-10.
2. Remove air filter assembly per § 71-21.
3. Remove hardware securing G057-1 or G058-1 cage assembly to firewall and
remove cage. Install suitable barrier to prevent foreign objects from entering
engine inlet.
B. Installation
1. Remove barrier, position G057-1 or G058-1 cage assembly against firewall, and
install hardware securing cage to firewall. Verify security.
2. Install air filter assembly per § 71-21.
3. Install tail rotor drive fan shaft per § 65-10.
71-23 Engine Inlet Bellmouth
A. Removal
1. Remove engine per § 71-10.
2. Refer to Figure 71-3. Remove F579-1 bellmouth cover and loosen B277-36
clamps securing bellmouth to engine front support. Remove bellmouth and
clamps.
3. Remove hardware securing F597-1 seal and F580-1 inlet to engine front support.
Remove seal and inlet. Install cover over front support.
B. Installation
1. Refer to Figure 71-3. Remove engine front support cover, install F580-1 inlet and
F597-1 seal (drain hole on bottom) on front support, and install hardware. Verify
security.
2. Install B277-36 clamps and F579-1 bellmouth over front support flange, and
tighten clamps. Verify security.
3. Install engine per § 71-10.
