Page 92.6 Chapter 92 ENG Version JUL 2020
92-52 D097-37 HD Micro Camera Installation (Aft-center Cabin)
A. Removal
1. Remove ILED-MA (aft talent) light per § 92-232.
2. Refer to Figure 92-1. Turn battery & news equipment switches off, and pull out
MICRO CAMS (2 amp) circuit breaker at panel.
3. Disconnect CV505/345-10FTCBLE cable and G459-756 wire from CV345-CS/
CSB camera at connectors.
4. Unscrew camera from RAM-B-366-201U arm assembly and remove camera.
B. Installation
1. Refer to Figure 92-1. Turn battery & news equipment switches off, and pull out
MICRO CAMS (2 amp) circuit breaker at panel.
2. Screw CV345-CS/CSB camera onto RAM-B-366-201U arm assembly Verify
security.
3. Connect CV505/345-10FTCBLE cable and G459-756 wire to camera at
connectors. Verify security.
4. Install ILED-MA (aft talent) light per § 92-232.
5. Push in MICRO CAMS circuit breaker (2 amp) at panel. Turn battery & news
equipment switches on.
6. Perform appropriate functional checks per Marshall Electronics CV345 Operation
Manual. Turn battery & news equipment switches off.
C. Special Inspections
1. Refer to Figure 92-1. Turn battery & news equipment switches off. Open news
equipment circuit breaker panel.
2. As required, remove CV345-CS/CSB micro camera per Part A. Inspect condition of
and verify no obvious damage to micro camera, RAM-B-366-201U arm assembly,
circuit breaker, and wiring. Verify no loose, chafed, or broken wires or terminals.
Verify no evidence of arcing. Verify equipment security.
3. Secure circuit breaker panel. Install micro camera per Part B if removed.
