95-50 Console Assemblies
NOTE
Refer to R66 Pilot's Operating Handbook Section 7 for views of
typical instrument panels, and the Optional Avionics Supplement
for views of panels with electronic flight displays.
A. Opening Console
Upper instrument panels that do not include Electronic Flight Displays (EFDs) or other
avionics may be "opened" by removing screws securing console assembly to forward
keel panels and hinging console aft. Secure console by hinging forward and installing
screws. If an EFD or any other avionics are installed in the upper instrument panel,
remove console per Part B.
B. Removing Console
1. Remove EFD if installed per § 95-70.
2. Remove avionics if installed and located in upper instrument console per Chapter 97.
3. Remove HeliSAS control panel if installed and located in upper instrument console
(not required if control panel is located at top of avionics stack).
4. Remove perimeter screws securing instrument face to console.
5. Disconnect instrument pitot-static lines. Plug lines.
6. Remove screws securing console assembly to forward keel panels and lower panel.
Remove console and disconnect console harness from airframe harness.
C. Installing Console
1. Connect console assembly harness to airframe harness and install screws securing
console to forward keel panels and lower panel.
2. Position instrument face in helicopter, remove plugs, and connect pitot-static lines.
3. Install perimeter screws securing face to console. Verify security.
4. Install HeliSAS control panel, if removed.
5. Install avionics per Chapter 97, if removed.
6. Install EFD per § 95-70, if removed.
7. Perform pitot-static system leak check per § 95-10.
95-60 Instrument Markings
See R66 Pilot’s Operating Handbook (POH) Section 2 for instrument markings.
Page 95.22 Chapter 95 Instrument System JUL 2020
