92-253 Digital Router
A. Removal
1. Refer to Figure 92-1. Turn battery & news equipment switches off, and pull out
AUDIO PANEL (5 amp) circuit breaker at panel.
2. Lift aft right seat forward. Remove or loosen screws securing G459 harness
assembly to G13000 router.
3. Remove screws and C130-51 spacers securing router to F387-1 (belly) skin and
remove router.
B. Installation
1. Refer to Figure 92-1. Turn battery & news equipment switches off, and pull out
AUDIO PANEL (5 amp) circuit breaker at panel.
2. Lift aft right seat forward. Install screws and C130-51 spacers securing G13000
router to F387-1 (belly skin). Verify security.
3. Install or tighten screws securing G459 harness assembly to router. Verify
security.
4. Push in AUDIO PANEL (5 amp) circuit breaker at panel.
5. Perform appropriate functional checks per Geneva Aviation user guide. Turn
battery & news equipment switches off.
C. Scheduled Inspections
Every 100-hour or annual inspection, inspect G13000 router for proper installation
(refer to R66 Illustrated Parts Catalog Chapter 92) & proper operation per Part B
steps 4 and 5.
D. Special Inspections
1. Refer to Figure 92-1. Turn battery & news equipment switches off. Open circuit
breaker panel.
2. As required, remove G13000 router per Part A. Inspect condition of and verify no
obvious damage to router, circuit breaker, and wiring. Verify no loose, chafed, or
broken wires or terminals. Verify no evidence of arcing. Verify equipment security.
3. Secure circuit breaker panel. Install router per Part A if removed.
Page 92.46 Chapter 92 ENG Version JUL 2020
