95-35 Fuel Quantity Gage
A. Description
The electric fuel quantity gage indicates relative fuel quantity. The variable resistance
sender is mounted near the fuel cap.
B. Schematic
Refer to Figure 98-1 for electrical schematic.
C. Removal
Remove G144-6 instrument cluster per § 95-31 Part C.
D. Installation
Install G144-6 instrument cluster per § 95-31 Part D.
E. Scheduled Maintenance and Inspections
Refer to § 5-45 100-Hour/Annual Inspection.
F. Special Maintenance and Inspections
Perform special maintenance and inspections per § 95-31 Part F.
APR 2017 Chapter 95 Instrument System Page 95.17
