92-54 D097 HD Micro Camera Controller
A. Removal
1. Refer to Figure 92-1. Turn battery & news equipment switches off, and pull out
MICRO CAMS (2 amp) circuit breaker at panel.
2. Remove screws securing G472 face to G471 panels and remove face.
3. Remove screws securing D344 support assembly to G472 face.
4. Cut and discard ty-raps as required and disconnect micro camera cable(s) from
CV505/345-10FTCBLE and/or CV200-M/MB cable controller(s) at connectors.
Detach controller(s) from support assembly (controllers are taped to support).
B. Installation
1. Refer to Figure 92-1. Turn battery & news equipment switches off, and pull out
MICRO CAMS (2 amp) circuit breaker at panel.
2. Connect micro camera cable(s) to CV505/345-10FTCBLE and/or CV200-M/MB
cable controller(s) at connectors. Verify security. Install ty-raps as required.
Cinch ty-raps until snug without overtightening, and trim tips flush with heads.
3. Position controller(s) on D344 support assembly. Install screws securing support
to G472 face. Verify security.
4. Install screws securing face to G471 panels. Verify security.
5. Push in MICRO CAMS circuit breaker (2 amp) at panel. Turn battery & news
equipment switches on.
6. Perform appropriate functional checks per Marshall Electronics CV200-MB/M or
CV345-CS/CSB Operation Manual. Turn battery & news equipment switches off.
C. Scheduled Inspections
Every 100-hour or annual inspection, inspect CV505/345-10FTCBLE and/or
CV200-M/MB cable controllers for proper installation (refer to R66 Illustrated Parts
Catalog Chapter 92) & proper operation per Part B steps 5 and 6.
D. Special Inspections
1. Refer to Figure 92-1. Turn battery & news equipment switches off. Open circuit
breaker panel.
2. As required, remove CV505/345-10FTCBLE and/or CV200-M/MB cable
controller(s) per Part A. Inspect condition of and verify no obvious damage to
cable controllers, circuit breaker, and wiring. Verify no loose, chafed, or broken
wires or terminals. Verify no evidence of arcing. Verify equipment security.
3. Secure circuit breaker panel. Install cable controller(s) per Part B if removed.
Page 92.10 Chapter 92 ENG Version JUL 2020
