92-232 ILED-MA (Aft Talent) Light
A. Removal
1. Refer to Figure 92-1. Turn battery & news equipment switches off and pull out
TALENT LTS (3 amp) circuit breaker at panel.
2. Unplug mini USB cable from ILED-MA light.
3. Using backup wrench on lower 91819A110 nut, loosen upper 91819A110 nut
securing light to 90322A645 stud; unscrew light off of stud.
B. Installation
1. Refer to Figure 92-1. Turn battery & news equipment switches off and pull out
TALENT LTS (3 amp) circuit breaker at panel.
2. Using backup wrench on lower 91819A110 nut, screw ILED-MA light onto
90322A645 stud; tighten upper 91819A110 nut securing light to stud. Verify
security.
3. Plug in mini USB cable to light.
4. Push in TALENT LTS (3 amp) circuit breaker at panel. Turn battery & news
equipment switches on. Verify talent light switches on and off using switch.
C. Scheduled Inspections
Every 100-hour or annual inspection, inspect ILED-MA light for proper installation (refer
to R66 Illustrated Parts Catalog Chapter 92) & proper operation per Part B step 4.
92-240 G491 TV Receiver Provision Installation
A. Description
Refer to Figure 92-1. The TV tuner is mounted in the rear equipment console and is
used to select television broadcasts to be displayed on the monitors. A second tuner
is optional.
B. Schematic
Refer to Figure 92-13 for G491 TV receiver provision installation wiring diagram.
Page 92.40
Chapter 92 ENG Version JUL 2020
