95-71 Garmin Display Unit (GDU) 1060 (continued)
F. Special Maintenance and Inspections
1. Remove GDU per § 95-71 Part C.
2. Open circuit breaker panel and upper console.
3. Inspect condition of and verify no obvious damage to GDU, copper bus bars,
circuit breaker, and wiring. Verify no loose, chafed, or broken wires or terminals.
Verify no evidence of arcing. Verify installed equipment security.
4. Secure circuit breaker panel and upper console.
5. Install GDU per § 95-71 Part D.
95-72 Garmin Display Unit (GDU) 620 Installation
NOTE
Refer to Garmin G500H Instructions for Continued Airworthiness.
A. Description
The GDU 620 integrates with the Garmin G500H Electronic Flight Instrument System
(EFIS). The GDU 620 electronically displays primary flight instrumentation via a
primary flight display (PFD) and moving map, weather, traffic, terrain and other
functionality via a multifunction display (MFD) on dual 6.5 inch displays.
Refer to § 97-10 for Garmin G500H EFIS system components.
B. Schematics
Refer to Figure 98-10 for GDU 620 installation electrical schematic.
Refer to Figures 95-3 & 95-5 for Garmin G500H upper console pitot-static schematic.
C. Removal
Remove GDU per § 95-71 Part C.
D. Installation
Install GDU per § 95-71 Part D.
E. Scheduled Maintenance and Inspections
Refer to Garmin G500H Instructions for Continued Airworthiness.
F. Special Maintenance and Inspections
Refer to § 95-71 Part F.
