JUL 2020 Chapter 92 ENG Version Page 92.11
92-60 F003-19 Seat Removal
Refer to Figure 92-1. ENG version helicopters have no aft center seat installed. The following
equipment is omitted: F628-4 connector assembly, center F628-6 buckle assembly, F931-
1 seat assembly, A752-3 angle, & (2) NAS1352-04-8 screw. Associate hardware is
replaced or omitted; refer to R66 Illustrated Parts Catalog for installation information.
92-70 Landing Gear Assembly
A. Description
Refer to Figure 92-1. The F014-5 extended landing gear raises the forward cross tube
approximately 2 inches higher off the ground, providing additional ground clearance
for optional equipment installations that project below the fuselage.
For ground handling, a second set of wheel installation supports is provided forward
on the landing gear skids. For ground handling using MT950 towcart, install wheels
at forward supports and use cart at aft cross tube as indicated on cart instructions
(online at www.robinsonheli.com). For ground handling without towcart, wheels may
be installed at all four support locations.
B. Maintenance Procedures
Refer to Chapter 32 for landing gear assembly maintenance procedures (identical to
standard gear maintenance procedures unless otherwise specified). Forward wheel
support maintenance procedures are located in § 92-40.
92-80 F060 Remote Transmit Switch Installations
A. Description
Refer to Figure 92-1. A handheld remote switch is installed at the co-pilot seat,
allowing the occupant to transmit on the radio selected without touching the flight
controls, or when the co-pilot flight controls are removed.
The switch plugs into a socket on the base of the seat.
B. Schematic
Refer to Figure 98-24 for F060 intercom system installation wiring diagram.
