JUL 2020 Chapter 90 Police Version Page 90.27
90-270 G749-1 Console Installation
A. Removal
1. Refer to Figure 90-1. Unlatch G750-1 tray and remove contents from G749-2
console assembly. Latch tray.
2. Remove screws securing console assembly to F377-1 support assembly, and
remove console.
B. Installation
1. Refer to Figure 90-1. Unlatch G750-1 tray and remove contents from G749-2
console assembly. Latch tray.
2. Position console on F377-1 support assembly and install screws. Verify security.
