Robinson R66 - G437-1 Lojack Installation

90-230 G437-1 Lojack Installation
A. Display Removal
1. Refer to Figure 90-1. Turn battery switch off & pull-out associated circuit breaker.
2. Disconnect cable from 4106-0006-00 display.
3. Remove screws securing D600-3 visor assembly and display to D436-6 support.
Remove visor and display.
B. Display Installation
1. Refer to Figure 90-1. Turn battery switch off & pull-out associated circuit breaker.
2. Connect cable to 4106-0006-00 display.
3. Position D600-3 visor assembly and display on D436-6 support and install screws.
Verify security.
4. Push-in associated circuit breaker & turn battery switch on. Perform appropriate
post-installation function checks. Turn battery switch off.
C. Receiver Removal
1. Refer to Figure 90-1. Turn battery switch off & pull-out associated circuit breaker.
2. Remove G428-1 wall assembly per § 90-220.
3. Remove screws securing two cable backshells to 4107-0003-10 receiver.
Disconnect all cables from receiver.
4. Remove screws securing receiver to G429-3 and G429-4 support assemblies, and
remove receiver.
D. Receiver Installation
1. Refer to Figure 90-1. Turn battery switch off & pull-out associated circuit breaker.
2. Remove G428-1 wall assembly per Section 90-220, if not previously accomplished.
3. Position 4107-0003-10 receiver on G429-3 and G429-4 support assemblies and
install screws. Verify security.
4. Connect all cables to receiver. Install screws securing two cable backshells to
receiver. Verify security.
5. Install G428-1 wall assembly per § 90-220.
6. Push-in associated circuit breaker & turn battery switch on. Perform appropriate
post-installation function checks. Turn battery switch off.
E. Schematic
Refer to Figure 90-15 for G437-1 Lojack installation wiring schematic.
Page 90.22 Chapter 90 Police Version JUL 2020
