90-130 F051-1 Camera System Installation (continued)
D. Controller Assembly Installation
1. Refer to Figure 90-1. Turn battery switch off & pull-out associated circuit breaker.
2. If removed, position D417-5 box on circuit breaker panel and install screws. Verify
security.
3. Connect D616-1 (FLIR camera) controller assembly plug to G458 harness receptacle.
Verify security.
4. Push-in associated circuit breaker & turn battery switch on. Perform appropriate
post-installation function checks. Turn battery switch off.
5. Holster controller assembly and secure with B219-4 strap assembly.
E. Electronics Control Unit Removal
1. Refer to Figure 90-1. Turn battery switch off & pull-out associated circuit breaker.
2. Remove G428-1 wall assembly per § 90-220.
3. Disconnect cable assemblies from 19206-2XX electronics control unit.
4. Remove MS27039C0805 screws securing control unit to D428-16 brackets and
G429-10 support, and remove control unit.
F. Electronics Control Unit Installation
1. Refer to Figure 90-1. Turn battery switch off & pull-out associated circuit breaker.
2. Remove G428-1 wall assembly per § 90-220, if not previously accomplished.
3. Position 19206-2XX electronics control unit on G429-1 support assemblies. Align
control unit, D428-16 brackets, and G429-10 support fastener holes and install
MS27039C0805 screws. Verify security.
4. Connect cable assemblies to control unit. Verify security.
5. Install wall assembly per § 90-220.
6. Push-in associated circuit breaker & turn battery switch on. Perform appropriate
post-installation function checks. Turn battery switch off.
G. Schematic
Refer to Figures 90-8 for F051-1 camera system installation wiring schematic.
90-140 F060 Intercom System Installation
Refer to Figure 90-1. The F060 intercom system installation includes a second floor switch.
Refer to § 90-70 for C823-16 audio control installation maintenance procedures.
