Page 92.4 Chapter 92 ENG Version JUL 2020
92-20 C023-24 Tailcone Assembly
A. Description
Refer to Figure 92-1. The C023-24 tailcone assembly has wiring provisions for the
ENG version’s D097-38 HD micro camera (tail).
B. Maintenance Procedures
Refer to § 53-40 for tailcone assembly maintenance procedures.
92-30 C599-7 Airspeed Indicator
A. Description
Refer to Figure 92-1. C599-7 (120 knot V
NE
, KM/H) airspeed indicator replaces C599-2
(140 knot V
NE
, KM/H) airspeed indicator.
B. Maintenance Procedures
Refer to § 95-22 for airspeed indicator maintenance procedures.
92-40 C720-1 Support Installation
A. Removal
Refer to Figure 92-1. Remove hardware securing C719-1 support to C242 skid tube
and remove support.
B. Installation
Install hardware securing C719-1 support to C242 skid tube, special torque bolt per §
20-33, and torque stripe per Figure 5-1.
92-50 HD Micro Camera Installations
A. Description
The micro camera system consists of three small cameras and their control units. The
micro cameras are mounted at the tip of the horizontal stabilizer, on the windshield
bow, and in the center of the cabin. The control units are located in the rear equipment
console. The horizontal stabilizer camera is enclosed in a weatherproof case.
B. Schematic
Refer to Figure 92-4 for D097 HD micro camera installation wiring diagram.
