JUL 2020 Chapter 92 ENG Version Page 92.5
92-51 D097-36 HD Micro Camera Installation (Windshield Bow)
A. Removal
1. Refer to Figure 92-1. Turn battery & news equipment switches off, and pull out
MICRO CAMS (2 amp) circuit breaker at panel.
2. Disconnect CV505/345-10FTCBLE cable and G459-2798 wire from CV345-CS/
CSB camera at connectors.
3. Remove D368-2 clamps securing wiring to windshield bow and remove camera.
4. As required, remove screws securing D368-8 mount and D368-10 plate to camera
and remove mount and plate.
B. Installation
1. Refer to Figure 92-1. Turn battery & news equipment switches off, and pull out
MICRO CAMS (2 amp) circuit breaker at panel.
2. If removed, install screws securing D368-10 plate and D368-8 mount to CV345-
CS/CSB camera. Verify security.
3. Install D368-2 clamps every six inches (5 maximum) securing wiring to windshield
bow. Verify security.
4. Connect CV505/345-10FTCBLE cable and G459-2798 wire to camera at
connectors. Verify security.
5. Push in MICRO CAMS circuit breaker (2 amp) at panel. Turn battery & news
equipment switches on.
6. Perform appropriate functional checks per Marshall Electronics CV345 Operation
Manual. Turn battery & news equipment switches off.
C. Scheduled Inspections
Every 100-hour or annual inspection, inspect CV345-CS/CSB micro camera for proper
installation (refer to R66 Illustrated Parts Catalog Chapter 92) & proper operation per
Part B steps 5 and 6.
D. Special Inspections
1. Refer to Figure 92-1. Turn battery & news equipment switches off. Open news
equipment circuit breaker panel.
2. As required, remove CV345-CS/CSB micro camera per Part A. Inspect condition
of and verify no obvious damage to micro camera, mount, circuit breaker, and
wiring. Verify no loose, chafed, or broken wires or terminals. Verify no evidence
of arcing. Verify equipment security.
3. Secure circuit breaker panel. Install micro camera per Part B if removed.
