25-74 Cyclic Grips, Electric Cargo Hook Release, Remote Equipment Provisions, and Left-
Seat Collective
A. Schematics
Refer to Figure 98-29 for cargo hook wiring schematic.
Refer to Figure 98-30 for external load controls wiring schematic.
Refer to Figure 98-31 for copilot instrument installation wiring schematic.
B. Removal and Installation
Refer to § 67-12 for cyclic grip assembly removal and installation procedures.
For removable cyclic grip, disconnect the electrical connectors located near the quick
release pin before removing the left cyclic grip. Reconnect the connectors when
installing the left cyclic grip.
For removable collective stick:
a. Removal: Unplug push-to-start button cable from jack. Unbutton boot and depress
locking pins to disengage and remove collective stick.
b. Installation: Depress locking pins and insert collective stick in control. Verify
both locking pins engage holes to secure stick; re-button boot. Plug in push-to-
start button cable to jack.
C. Scheduled Inspections
Refer to § 5-45 100-Hour/Annual inspection.
