25-60 Emergency Equipment
25-61 Emergency Locator Transmitter (ELT)
A. Description
The ELT activates when subjected to a significant change in velocity (as in a crash),
by remote control switch located on the cyclic control panel, or by a switch on the
ELT transmitter. Refer to § 96-90 for system description.
Refer to Kannad Aviation AF Integra / AF-H Integra or 406 AF-Compact/406 AF-
Compact (ER) ELT Installation and Operation Manual for maintenance requirements
and procedures. Refer to § 5-20 for scheduled maintenance.
Register an ELT when first purchased, when contact information changes, or when
aircraft ownership, or tail number changes. Registration information is available
online at: www.cospas-sarsat.org.
Dongles contain a memory chip that must be programmed with aircraft-specific
information prior to installation for the ELT to function. The dongle may be removed
and shipped to RHC or a Kannad Service Center for reprogramming. Kannad Aviation’s
Programming Data Sheet is available online at: www.robinsonheli.com.
B. Transmitter
Removal
1. Release D693-4 strap assembly or B359-2 (reusable) ty-rap.
2. Release Velcro strap; disconnect dongle and antenna wiring from transmitter at
connectors and remove transmitter.
Installation
1. Connect dongle and antenna wiring to transmitter at connectors. Verify security.
2. Position transmitter on mounting bracket and secure with Velcro strap. Secure
D693-4 strap assembly or install B359-2 (reusable) ty-rap around transmitter
and bracket. Verify security.
C. Dongle
Removal
Cut and discard ty-raps as required, disconnect dongle from transmitter and airframe
harness at connectors, and remove dongle.
Installation
1. Connect programmed dongle to transmitter and airframe harness at connectors.
2. Install ty-raps as required. Cinch ty-raps until snug without over-tightening, and
trim tips flush with heads. Verify security.
Page 25.14 Chapter 25 Furnishings APR 2019
