JUL 2020 Chapter 92 ENG Version Page 92.25
92-172 E002-2 Laptop Assembly
A. Removal
1. Refer to Figure 92-1. Turn battery & news equipment switches off and pull out
GIMBAL CAMERA (10 amp) circuit breaker at panel.
2. Disconnect G459 harness assembly from E002-2 laptop assembly and remove
laptop.
B. Installation
1. Refer to Figure 92-1. Turn battery & news equipment switches off and pull out
GIMBAL CAMERA (10 amp) circuit breaker at panel.
2. Connect G459 harness assembly to E002-2 laptop assembly.
3. Push in GIMBAL CAMERA (10 amp) circuit breaker at panel. Turn battery & news
equipment switches on.
4. Perform appropriate function checks per § 92-171 Part C.
C. Scheduled Inspections
Every 100-hour or annual inspection, inspect E002-2 laptop assembly for proper
installation (refer to R66 Illustrated Parts Catalog Chapter 92) & proper operation per
Part B steps 3 and 4.
D. Special Inspections
1. Refer to Figure 92-1. Turn battery & news equipment switches off. Open circuit
breaker panel.
2. As required, remove E002-2 laptop assembly per Part A. Inspect condition of
and verify no obvious damage to laptop, circuit breaker, and wiring. Verify no
loose, chafed, or broken wires or terminals. Verify no evidence of arcing. Verify
equipment security.
3. Secure circuit breaker panel. Install laptop per Part B if removed.
