Page 92.12 Chapter 92 ENG Version JUL 2020
92-90 F075-1 EFIS Installation
A. Description
Refer to Figure 92-1. The R66 ENG version is equipped with the Garmin G500H
Electronic Flight Instrument System (EFIS).
B. Maintenance Procedures
Refer to §§ 95-70 & 97-10 for Garmin G500H EFIS maintenance procedures.
92-100 F082-21 Fairing Installation
A. Description
Refer to Figure 92-1. Extended landing gear F082-21 strut fairings are longer than but
are otherwise identical to standard strut fairings. F082-21 fairing installation replaces
F082-1 fairing installation.
B. Maintenance Procedures
Refer to § 32-40 fairing assemblies for maintenance procedures.
92-110 F461-4 Cover Assembly
Refer to Figure 92-1. Refer to R66 Illustrated Parts Catalog Chapter 6 for access and
inspection panel locations. F461-4 cover assembly replaces F461-1 cover assembly.
92-120 G197-13 Window
A. Description
Refer to Figure 92-1. The G197-13 window illuminates the ENG version instrument
console for night lighting. G197-13 window replaces G197-9 window.
B. Maintenance Procedures
Refer to § 33-21 for panel light maintenance procedures. Adjust window laterally as
required to ensure even light spread on console.
