JUL 2020 Chapter 90 Police Version Page 90.19
90-200 G416 Monitor Installation
A. Description
The G416-1 monitor installation (earlier helicopters) hinges forward and down for
stowing. The G416-4 and G416-5 monitor installation hinges forward at the right
edge to stow alongside the console.
B. Schematic
Refer to Figure 90-12 for G416-1 monitor installation wiring schematic.
Refer to Figure 90-13 for G416-4 monitor installation wiring schematic.
Refer to Figure 90-14 for G416-5 monitor installation wiring schematic.
C. Removal
G416-1 Monitor Installation
1. Turn battery switch off and pull-out MONITOR (2 amp) circuit breaker at panel.
2. Disconnect cables from V-R1041-RH monitor.
3. Remove hardware securing MS21919WDG8 clamp to monitor.
4. Support monitor. Remove A483-1 knob with associated hardware, and DK-225
knob with associated hardware, securing monitor to D409-8 pivot assembly.
Remove monitor.
5. Remove screws securing D763-3 visor assembly to monitor.
G416-4 Monitor Installation
1. Turn battery switch off and pull-out MONITOR (2 amp) circuit breaker at panel.
2. Disconnect G458 harness assembly cables from DVI 10LDB_RH monitor.
3. Remove screws securing monitor to G417-1 pivot assembly and G417-4 tray
assembly and remove monitor.
G416-5 Monitor Installation
1. Turn battery switch off and pull-out MONITOR (2 amp) circuit breaker at panel.
2. Disconnect G458 harness assembly cables from BHB12HDR15 monitor.
3. Remove screws securing monitor to G417-5 pivot assembly and G417-7 tray
assembly and remove monitor.
