92-53 D097-38 HD Micro Camera Installation (Tail; continued)
B. Installation (continued)
2. Install grommet on CV200-M/MB camera cable. Tape camera cable connector to
4.5-ft length of lockwire; route lockwire thru horizontal stabilizer toward gearbox
and thru opposite hole. Pull camera cable thru stabilizer, remove taped lockwire,
and connect C023 wires to cable at connectors. Verify security.
3. Refer to Figure 92-2. Position D368-11 clamp on camera (clamp slot on bottom)
with camera protruding 1.5 inches from clamp as shown. Install screws securing
clamp and camera to horizontal stabilizer. Verify security.
4. Secure inboard and outboard horizontal stabilizer grommets.
5. Push in MICRO CAMS (2 amp) circuit breaker at panel. Turn battery & news
equipment switches on.
6. Perform appropriate functional checks per Marshall Electronics CV200-M/MB
Operation Manual. Turn battery & news equipment switches off.
C. Scheduled Inspections
Every 100-hour or annual inspection, inspect CV200-M/MB micro camera for proper
installation (refer to R66 Illustrated Parts Catalog Chapter 92) & proper operation per
Part B steps 5 and 6.
D. Special Inspections
1. Refer to Figure 92-1. Turn battery & news equipment switches off. Open circuit
breaker panel.
2. As required, remove CV200-M/MB micro camera per Part A. Inspect condition
of and verify no obvious damage to micro camera, horizontal stabilizer tip and
doubler, circuit breaker, and wiring. Verify no loose, chafed, or broken wires or
terminals. Verify no evidence of arcing. Verify equipment security.
3. Secure circuit breaker panel. Install micro camera per Part B if removed.
