JUL 2020 Chapter 90 Police Version Page 90.25
90-250 G608 GPS Mapping System Installation (continued)
D. Installation
Viewsync3D Computer
1. Turn battery switch off and pull out VIEWSYNC (5 amp) circuit breaker at panel.
2. Position Viewsync3D computer on isolator mounting tray and install hardware.
Verify security.
3. Connect cables to computer.
4. Install G428-1 wall assembly per MM § 90-220.
5. Push in VIEWSYNC (5 amp) circuit breakers at panel. Turn battery & avionics
switches on.
6. Perform appropriate functional checks per Aerocomputers Airborne Systems UC-
5300 Operating Instructions. Turn battery & avionics switches off.
UC-5300/6000 Computer
1. Turn battery switch off and pull out GPS MAP (5 amp) circuit breaker at panel.
2. Position UC-5300/6000 computer on isolator mounting tray and install hardware.
Verify security.
3. Connect cables to computer.
4. Install G428-1 wall assembly per MM § 90-220.
5. Push in GPS MAP (5 amp) circuit breakers at panel. Turn battery & avionics
switches on.
6. Perform appropriate functional checks per Aerocomputers Airborne Systems UC-
5300/6000 Operating Instructions. Turn battery & avionics switches off.
IMU Sensor (if installed)
1. Turn battery switch off and pull out GPS MAP (5 amp) circuit breaker at panel.
2. Position IMU Sensor on G429-15 support assembly and install hardware. Verify
security.
3. Connect cables to IMU Sensor.
4. Install hardware securing G702-9 cover assembly to seat assembly.
5. Install F445-1 and F680-3 cover assemblies and hinge forward left seat aft.
6. Push in GPS MAP (5 amp) circuit breakers at panel. Turn battery & avionics
switches on.
7. Perform appropriate functional checks per Aerocomputers Airborne Systems UC-
5300 Operating Instructions. Turn battery & avionics switches off.
To Next Page
