92-210 G487-1 FM Transceivers Installation (continued)
C. Removal
1. Refer to Figure 92-1. Turn battery & news equipment switches off and pull out
FM2 (10 amp) and FM3 (10 amp) circuit breakers at panel.
2. Remove screws securing G472 face to G471 panels.
3. Disconnect G459 harness assembly from A824 transceiver(s).
4. Supporting transceiver(s), remove hardware securing B344-25 angle assemblies to
face and transceiver(s). Remove angles and transceiver(s).
D. Installation
1. Refer to Figure 92-1. Turn battery & news equipment switches off and pull out
FM2 (10 amp) and FM3 (10 amp) circuit breakers at panel.
2. Supporting A824 transceiver(s), install hardware securing B344-25 angle assemblies
to face and transceiver(s). Verify security.
3. Install screws securing G472 face to G471 panels.
4. Connect G459 harness assembly to transceiver(s).
5. Push in FM2 (10 amp) and FM3 (10 amp) circuit breakers at panel. Turn battery &
news equipment switches on.
6. Perform appropriate functional checks per Kenwood TK-7180/TK-8180 VHF FM /
UHF FM Transceiver Instruction Manual. Turn battery & new equipment switches off.
E. Scheduled Inspections
Every 100-hour or annual inspection, inspect A824 transceiver(s) for proper installation
(refer to R66 Illustrated Parts Catalog Chapter 92) & proper operation per Part D steps
5 and 6.
F. Special Inspections
1. Refer to Figure 92-1. Turn battery & news equipment switches off. Open circuit
breaker panel.
2. As required, remove A824 transceiver(s) per Part A. Inspect condition of and
verify no obvious damage to transceiver(s), circuit breaker, and wiring. Verify no
loose, chafed, or broken wires or terminals. Verify no evidence of arcing. Verify
equipment security.
3. Secure circuit breaker panel. Install transceiver(s) per Part A if removed.
JUL 2020 Chapter 92 ENG Version Page 92.37
