7.5. ROTARY RING HANDLING
The ring will always stop with spool synchronised; if manual spool carriage unit rotation is necessary proceed as follows.
1. Switch the machine off.
2. Release the motor brake by tightening the screw (A) completely; the spool carriage unit is now free to rotate.
3. Completely loosen the screw to block motor brake again; screw removal is recommended when not in use.
