5.7. ADJUSTMENT OF SPOOL CARRIAGE ROLLER CLUTCH
The spool carriage roller clutch avoids that, due to spool inertia, too much film than required is unwound during the cycle.
The optimum adjustment must be performed with the heaviest spool available, that is, the one with greater inertia, and
must guarantee that the film wraps always remain well compacted on the spool.
1. Display the main page.
2. Touch the key (A) to access the manual movements (see paragraph 6.3. “Description of control panel” -
“Description of control panel manual controls”).
3. Touch the slewing ring (B) key to enable it and then the “spool” key (C).
The spool carriage unit automatically moves in front of the door (D).
4. Open the door (D) to access to the spool clutch adjustment.
5. Adjust the clutch on the spool carriage roller using the knob (E); turn clockwise to increase the braking effect.
6. Close the door and press the reset push-button.
7. Press the “Home” (F) key to return to the main page and to set up the machine.
