Robopac Compacta S9 - Roller or Skid Guides Adjustments (Optional)

ENG
INFORMATION ON ADJUSTMENTS
62
5.3. ROLLER OR SKID GUIDES ADJUSTMENTS (OPTIONAL)
Width
1. Insert guides on the side of the conveyors in positions 1.
2. Fix the guides with 2 M8 screws.
3. According to the product to be wrapped, adjust the guides by regulating knobs (A).
4. Adjust guide position so as to keep the product as much as possible in the middle of the belt.
Caution - warning
To prevent the guides from squeezing the product leave 1÷3 cm between the product and the guides on
each side.
