3.9. INSTALLATION ENVIRONMENT CHARACTERISTICS
The place where the machine is to be installed must be carefully selected taking into account the environment conditions
in order to have correct and risk-free operating conditions.
Therefore we suggest to take into account the following prerequisites:
- Ambient temperature between +0°C and 40°C.
- An environment sufficiently ventilated to have, during use, humidity values that are pleasant for the operator.
- The ambient lighting must have a normal value in order to create a pleasant and relaxing environment for those
using the machine.
- A perimeter area that must be left around the immediate working area, also for safety reasons, as shown in the
figure.
- A flat surface, steady and without vibrations with adequate load bearing capacity.
The area must be equipped with a power supply socket and a compressed air supply socket.
1. Operator workstation (*)
2. Perimeter area
3. Product outfeed area (*)
4. Lateral guide adjustment area
5. Compressed air connection point
6. Power connection point
(*) These areas must be suitably sized to the product being processed.
