2.8. INFORMATION AND SAFETY SIGNS
The figure indicates the position of the safety and information signs affixed to the machine.
For each sign the relative description is specified.
1. Electrical hazard sign
Electrical shock hazard, do not access inside live element.
2. Information sign
It shows the insertion points for the lifting forks.
3. Prohibition sign
Do not act on the component with your hands.
4. Danger sign
Cutting danger.
5. Information sign
Ring rotation direction.
6. Information sign
Electrical disconnector.
7. Danger sign
Hand crushing danger.
8. Information sign
Film winding diagram.
9. Information sign
Vernier, position reference.
10. Information sign
Film passage plate.
11. Obligation sign
Obligation to read instructions.
12. Prohibition sign
It prohibits the presence of more than one operator.
Important
Make sure that the nameplates are clearly legible.
If not, replace and reposition them at the original position.
