6.3.2. MAIN PAGE
The page displays the wrapping values currently in use and gives access the other pages.
A) It displays the name of the recipe in use.
B) Key to access the wrapping number setting (See "Cycle parameters setting").
C) Main display, shows the wrapping cycle selected in the active recipe (See "Cycle parameters setting").
D) Button to access the recipe list.
E) It displays the enabled operator.
F) Software changes key (see “Description of control panel”-“Date and time setting”).
G) Key to access manual movements.
H) Key to access the setting of the wrapping start time (See "Cycle parameters setting").
I) Key to access the setting of the speed of the rotary ring and of the conveyors (See "Cycle parameters setting").
L) Key to access the setting of the product wrapping interval time (See "Cycle parameters setting").
M) Key to access the setting of the product wrapping end time (See "Cycle parameters setting").
N) On-off key enables/disables film breakage control (Optional).
O) On-off key enables/disables the advance of the outfeed presser downstroke (Optional).
P )On-off key enables/disables the heat sealing and if enabled the heat sealing allows to set the sealing time
(Optional).
R) Cycle reset key.
S) It displays the machine status.
- S1: Machine in Stop.
- S2: Machine in Reset.
- S3: Machine in Automatic mode.
T) Key to access to the setting of additional band number (the key is only present if the “Head and additional bands
wrapping” cycle has been selected).
U )On-off key enables/disables the downstroke of the pressers during the cycle (Optional).
V ) Film insertion key (Clamp forward-backward).
