Robustel GoRugged R3000 Lite User Guide
RT_UG_R3000 Lite_v.1.4.1 15.11.2016 36 / 135
Confidential
Basic @Cellular WAN
Cellular Settings
Item
Description
Default
Status
There are the possible statuses of cellular SIM card.
"Inserted",
"Ready",
"Need SIM PIN",
"Need SIM PUK",
"Check SIM error",
"Input PIN Code error",
"Input PUK Code error",
"Poor signal",
"Registration fails",
"initializing APN fails",
"Linkup fails";
"Not inserted"
/
Network Provider Type
Select from “Auto”, “Custom” or the ISP name, you may click
Configuration > Cellular WAN > ISP Profile.
Auto: Router will get the ISP information from SIM card, and set the APN,
username and password automatically. This option only works when the
SIM card is from well-known ISP.
Custom: Users need to set the APN, username and password manually.
Auto
APN
Access Point Name for cellular dial-up connection, provided by local ISP.
Null
Username
User Name for cellular dial-up connection, provided by local ISP.
Null
Password
Password for cellular dial-up connection, provided by local ISP.
Null
Dialup No.
Dialup number for cellular dial-up connection, provided by local ISP.
*99***1#
PIN Type
Select from “None”, “Input”, “Lock”, “Unlock”.
None: Select when SIM card does not enable PIN lock or PUK lock.
Input: Select when SIM card has enabled with PIN lock or PUK lock.
Correct PIN/PUK code need to be entered.
Lock: Select when user needs to lock the SIM card with PIN or PUK code.
Unlock: Select when user needs to unlock the SIM card with PIN or PUK
code.
Note: Please ask your local GSM ISP to see whether your SIM card
requiring PIN or not. If you want to change with a new PIN code, you need
to input new PIN code in item “New PIN Code” and “Confirm New PIN
Code”. You can go to tab Status > Event/Log > AT+CPIN? to check what
the status of the SIM card is.
None
PPPoE Bridge Setting
Enable PPPoE Bridge
Click to enable PPPoE Bridge setting.
Disable
Connection Mode
Connection Mode
Select from “Always Online” and “Connect On Demand”.
Always Online: Auto activates PPP and keeps the link up after power on.
Connect On
Demand
