Robustel GoRugged R3000 Lite User Guide
RT_UG_R3000 Lite_v.1.4.1 15.11.2016 37 / 135
Confidential
Connect On Demand: After selection this option, user could configure
Triggered by Serial Data, Triggered by Periodically Connect and Triggered
by Time Schedule.
Note: If you select several connect on demand polices, router only have to
meet one of them to be triggered.
Redial Interval (s)
Router will automatically re-dial with this interval when it fails
communicating to peer via TCP or UDP.
30
Max Retries
The maximum retries times for automatically re-connect when router
fails to dial up. After maximum retries, router will reboot the wireless
module. If router still cannot dial up successfully, it will try to switch to
the other SIM card. Then router will re-connect with the other SIM card
with maximum retries. After successful connection, the Max Retries
counter will be set to 0.
3
ICMP Detection Primary
Server
Router will ping this primary address/domain name to check that if the
current connectivity is active.
8.8.8.8
ICMP Detection
Secondary Server
Router will ping this secondary address/domain name to check that if the
current connectivity is active.
8.8.4.4
ICMP Detection Interval
(s)
Set the ping interval time.
Null
ICMP Detection
Timeout (s)
Set the ping timeout.
30
ICMP Detection Retries
If Router ping the preset address/domain name time out continuously for
Max Retries time, it will consider that the connection has been lost.
3
Reset The Interface
Enable to reset the cellular/ETH interface after the max ICMP detection
retries.
3
Inactivity Time (s)
Set the auto disconnect time when no data flow produced.
0
Serial Output Content
(Hex)
The content which output to the serial device which connect to router
and inform it that router is ready to receive serial data.
Null
Triggered by Serial Data
Tick this check box to allow router automatically connects to cellular
network from idle mode when there is data comes out from serial port.
Enable
Triggered by Tel
Tick this check box to allow router automatically connects to cellular
network from idle mode when make a voice call to router.
Disable
Triggered by SMS
Tick this check box to allow router automatically connects to cellular
network from idle mode when send a specific SMS to router.
Disable
SMS Connect Command
Users shall send this specific SMS to trigger router to connect to cellular
network.
Null
SMS Disconnect
Command
Users shall send this specific SMS to trigger router to disconnect to
cellular network.
Null
SMS Connect Reply
When router connects to cellular network, it will automatically send out
this SMS to specific users (set in the Phone Group).
Null
SMS Disconnect Reply
When router disconnect from cellular network, it will automatically send
out this SMS to specific users (set in the Phone Group).
Null
Phone Group
Click to add Phone Group to Set specific users’ phone Book and which
Null
