Robustel R1520 User Manual

Robustel R1520 User Guide
RT056_UG_R1520_v.1.0.3 Dec. 25, 2021 13/159
 Measuring range: 4 ~ 20mA / 0 ~ 24V
Others
 1 x Reset button (Tact Switch)
 1 x 480 Mbps high-speed USB 2.0 interface (host mode), Type A, 5V / 500 mA
 LED indicators - 1 x RUN, 1 x Modem, 1 x USR, 1 x WiFi, 1 x RSSI
Power Supply and Consumption
 Connector: 2-pin 3.5 mm female socket with lock
 Input voltage: 9 to 36V DC
 Power consumption: Idle: 100 mA@12 V;
Data link: 1000 mA (peak) @12 V
Physical Characteristics
 Ingress protection: IP30
 Housing & Weight: Plastic, 250 g
 Dimensions: 105mm (length) x 90mm(width) x 46mm(thickness)
 Installations: Desktop, wall mounting or DIN rail mounting (Wall mounting and Din rail mounting installation
requires additional installation accessories)
 Operating Temperature: -25~+70 °C
 Storage Temperature: -40~+85 °C
 Relative Humidity: 5~95% RH
1.4 Dimensions
