Filtering
Item
Description
Default
the connecting requests except the hosts which fit this accept
filtering list
 Drop: When Default Filtering Policy is accept, router will accept all
the connecting requests except the hosts which fit this drop
filtering list
Port Mapping
Port mapping is defined manually in the router, and the data received from some ports in the public network are all
forwarded to a port of an IP in the internal network. Click "network > firewall > port mapping" to display as follows:
Click to add port mapping rules. The maximum rule count is 50.
Port Mapping Rules
Item
Description
Default
Index
Indicate the ordinal of the list.
--
Description
Enter a description for this port mapping.
Null
Remote IP
Specify the host or network which can access to the local IP address.
Empty means unlimited. e.g. 10.10.10.10/255.255.255.255 or
192.168.1.0/24
Null
Internet Port
Set the internet port of router which can be accessed by other hosts from
internet.
Null
Local IP
Enter router’s LAN IP which will forward to the internet port of router.
Null
Local Port
Enter the port of router’s LAN IP.
Null
Protocol
Select from “TCP”, “UDP” or “TCP-UDP” as your application required.
TCP-UDP
