Rockwell Automation Publication 2080-QS004C-EN-E - October 2023 29
Chapter 5
Connect the Input Simulator Board
Connect the input simulator boards as shown in Figure 1 or Figure 2.
Figure 1 - Micro820 Controller Input Simulator Board Wiring Diagram
Analog Output
Potentiometer
SW11-I00
SW12-I01
SW13-I02
SW14-I03
GND
+24V DC
GND+24V DC
Can optionally be wired to an
analog input plug-in or expansion
I/O module
