Rockwell Automation Publication 440R-UM013G-EN-P - December 2022 79
Appendix A Specifications
B1 Input
Safety Outputs
Attribute
440R-S13R2
(CI)
440R-D22R2
(DI)
440R-D22S2
(DIS)
440R-EM4R2
(EM)
440R-EM4R2D
(EMD)
440R-S12R2
(SI)
Wiring terminal ———— B1—
On voltage
Max [V] ————26.4—
Min [V] ———— 11—
Off voltage, max [V] ———— 5—
Off current, max [mA] ———— 2—
On current,
max
At 24V DC [mA]————11.0—
At 26.4VDC [mA]————11.1—
Galvanic isolation: I/O from Logic————No—
Overvoltage protection ————Yes—
Input capacitance [nF] ————10—
Attribute
440R-S13R2
(CI)
440R-D22R2
(DI)
440R-D22S2
(DIS)
440R-EM4R2
(EM)
440R-EM4R2D
(EMD)
440R-S12R2
(SI)
Wiring terminal
13/14, 23/24,
33/34
13/14, 23/24 14, 24, 34, 44
13/14, 23/24,
33/34, 43/44
17/18, 27/28,
37/38, 47/48
13/14, 23/24
Output type 3 N.O. 2 N.O. 4 PNP 4 N.O. 4 N.O. delayed 2 N.O.
Thermic current I
th
[A]
1 x 6 — 1 x 6
Fuses output
(external) [A]
Slow blow 6
—
6
Quick blow 10 10
Switched current, min [mA] 10 — 10
Switched voltage, min [V] 10 — 10
Mechanical life 10,000,000 cycles — 10,000,000 cycles
Rating
UL: C300
AC-15: 1.5 A / 250V AC
DC13: 2 A / 24V DC (0.1 Hz)
14, 24: 1.5 A each
34, 44: 0.5 A each
UL: B300
AC-15: 1.5 A / 250V AC
DC13: 2 A / 24V DC (0.1 Hz)
UL: C300
AC-15: 1.5 A/
250V AC
DC13: 2 A/
24V DC (0.1 Hz)
Capacitance —
14, 24: 1.6 µF each
34, 44: 9 µF each
—
Contact material AgNi
AgNi +
0.2 µ Au
—AgNi
Reaction time
safety output
[ms]
L12 — 45 40 100 45 —
Inputs
150
35 25
—— 150
Mat operation 40 30
Reaction time
single wire
safety output
[ms]
L12 — 40 45 0 45 —
Inputs 25 25 25
——
25
Mat operation 30 30 30 30
Reaction time
to jog, max
[ms]
B1 — — — — 35 —
Response
time
safety output
[ms]
L12 45 45 45 45 45 45
Inputs 35 35 25
——
35
Mat operation 45 45 35 45
Response
time
single wire
safety output
[ms]
L12 45 45 45 45 45 45
Inputs 25 25 25
——
25
Mat operation 40 35 35 35
Single-wire
fault
55 50 50
(1)
(1) Response time of the single-wire source device.
45 50
Response
time to jog,
max [ms]
B1 — — — — 35 —
