100 Rockwell Automation Publication ICSTT-RM447M-EN-P - July 2019
Chapter 6 Specifying a New Controller
Estimate AADvance
Controller Weight
Use the following table to make an estimate of the weight of your controller.
Table 18 - AADvance Controller Module Weight
System Installation
Environment
The installation environment can be a source of common cause failure so it is
necessary that the installation assessment covers the environmental
specification for the AADvance system and includes the following:
• the prevailing climatic conditions
• type of area, e.g. is it a hazardous or non-hazardous area
•location of power sources
• earthing and EMC conditions
In some customer installations parts of the system can be installed in differing
locations; in these cases the assessment must include each location.
Power Sources and Heat Dissipation Calculations
It is highly recommended that module supply power and field loop power
consumption calculations are done to find out the heat dissipation before
designing a suitable enclosure and making a decision about the installation
environment (see topic "System Design for Heat Dissipation").
Item Number Used Weight Allowance g (oz.) Subtotal
T9100 Processor Base Unit × 460 g (16 oz.)
T9110 Processor Module × 430 g (15 oz.)
T9401 Digital input module, 24 Vdc, 8 channel × 280 g (10 oz.)
T9402 Digital input module, 24 Vdc, 16 channel × 340 g (12 oz.)
T9431 Analogue input module, 8 channel × 280 g (10 oz.)
T9432 Analogue input module, 16 channel × 340 g (12 oz.)
T9451 Digital output module, 24 Vdc, 8 channel × 340 g (12 oz.)
T9482 Analogue output module, 8 channel × 290 g (10.5 oz.)
T9300 I/O base unit (3 way) × 133 g (5 oz.)
T98x1 Simplex Termination assembly × 133 g (5 oz.)
T98x2 Dual Termination Assembly × 260 g (10 oz.)
T98x3 Triple Termination Assembly × 360 g (13 oz.)
T9310 Expansion cable assembly and 2 m cable × 670 g (24 oz.)
T9841 Termination Assemblies (average weight) × 175 g (6 oz.)
Total estimated controller weight
