88 Rockwell Automation Publication ICSTT-RM447M-EN-P - July 2019
Chapter 4 AADvance System Architectures
The controller Ethernet ports are found on the T9110 processor base unit and
identified like this:
Table 16 - Allocation of 10/100BASE-TX Ports to Processor Modules
Specifying a Safety Network
Once a system uses distributed controllers with shared data, the topology of
the safety network must be robust. To do this, make sure the network has no
single point of failure, refer to the AADvance Safety Manual (Document:
ICSTT-RM446) for further details about specifying a safety Network.
10/100BASE-TX Ports T9110 Processor Module
E1–1, E1–2 Processor A
E2–1, E2–2 Processor B (if fitted)
E3–1, E3–2 Processor C (if fitted)
