Module Overview and Specifications Chapter 7
T9100 Base Unit Specification
Table 24 - T9100 Processor Base Unit Specification
Attribute Value
Electrical Specification
Supply voltage requirements Redundant + 24 Vdc nominal; 18 Vdc to 32 Vdc range
Number of processor modules supported 1, 2 or 3
Number of I/O base units supported 16: 8 for each I/O bus
E1-1, E1-2; E2-1, E2-2; E3-1, E3-2 Connectors for Ethernet Ports 1 & 2 for Processor A, B and C
Wiring: shielded RJ45 sockets according to IEC6063-7, 2- or 4-pair
shielding
S1-1, S1-2; S2-1,S2-2; S3-1, S3-2 Connectors for Serial Ports 1 & 2 for Processor A, B and C
Wiring: Six 5-way connectors; maximum 1.31 mm² (16 AWG), Stripping
length 7 mm (9/32 in.)
PWR-1, PWR-2 Connectors for Redundant +24Vdc Power Supplies.
Wiring: Two 3-way connectors, Conductor cross section maximum 3.3
mm² (12 AWG); Stripping length 7 mm (9/32 in.)
FLT Not used
KEY Connector for the Program Enable Key
Mechanical Specification
Dimensions (height × width × depth) 235 mm x 126 mm
(9 1/4 in. x 5 in.)
Weight 460g (16 oz.)
