134 Rockwell Automation Publication ICSTT-RM447M-EN-P - July 2019
Chapter 7 Module Overview and Specifications
T9881/2 Termination
Assemblies for Analogue
Outputs
T9881 is a simplex 8 channel termination assembly and T882 is the dual
termination assembly. Each channel has a capacitor in series with the output.
T9881/2 Analogue Output Termination Assembly Specification
Table 34 - Analogue Output Module TA Specification
Load impedance
Maximum range 0 - 750 Ω limited by compliance voltage
Typical 250 Ω
Maximum field loop power dissipation 0.77 W for each field loop (2.63BTU/hr.)
Mechanical Specification
Dimensions (height × width × depth) 166 mm × 42 mm × 118 mm
(6-½ in. × 1-21/32 in. × 4-21/32 in.)
Weight 290 g (10.5 oz.)
Casing Plastic, non flammable
Attribute Value
Attribute Value
Functional Characteristics
Field connections 8; Wiring: Conductor cross section
maximum 1.31 mm² (16 AWG); Stripping length
6mm (¼ in.)
Modules supported T9881: One
T9882: Two
Electrical Characteristics
Channel isolation ± 1.5 kVdc maximum withstand for 1 minute
Mechanical Specification
Dimensions (height x width)
T9881 132 mm × 42 mm (5-¼ in. × 1-21/32 in.)
T9882 13 2mm × 84 mm (5-¼ in. × 3-5/16 in.)
Weight
T9881 133 g (5 oz.)
T9882 260 g (10 oz.)
