Rockwell Automation Publication ICSTT-RM447M-EN-P - July 2019 133
Module Overview and Specifications Chapter 7
communicate with each other by an inter-module link to maintain fault
tolerant operation'.
This module supports HART commands #03 to collect data from the field
device. The application can be configured to use HART information to
monitor and respond to device conditions. It may also be used to supply
diagnostic information such as comparison and error reporting.
T9481/2 Analogue Output Module Specification
Table 33 - Analogue Output Module Specification
Attribute Value
Functional Characteristics
Output channels T9481: 3
T9482: 8
Performance Characteristics
Safety integrity level
Safety level degradation 1oo1D, 1oo2D
Safety accuracy 200 μA
Self-test interval < 1 hour, system dependent
Value of least significant bit (control) 0.98 μA
Value of least significant bit (monitor) 3.9 μΑ
Error at 25 °C ± 2 °C
After 1 year at 40 °C
After 2 years at 40 °C
After 5 years at 40 °C
0.30 % + 10 μΑ
0.35 % + 10 μΑ
0.44 % + 10 μΑ
Temperature drift (0.01 % + 0.1 μA) for each °C
Electrical Characteristics
Module supply voltage:
Voltage Redundant +24 Vdc nominal;
18 Vdc to 32 Vdc range
Module supply power dissipation 3.6 W (12.3 BTU/hr.)
Output voltage:
Maximum voltage without damage ± 60 Vdc
Operating field supply voltage 18 - 32 Vdc
Output current
Nominal 4 - 20 mA
Maximum range 0.1 - 24 mA
Calibrated accuracy at 25 °C 10 μA
Output current control resolution 0.98 μA, 15-bit
Output current control accuracy at 25 °C ± 10 μΑ
Output current monitoring resolution 3.9 μΑ, 13-bit
Compliance voltage 3 Vdc to 32 Vdc
Maximum Compliance voltage slew rate No limit identified within Compliance voltage range.
