Rockwell Automation Allen-Bradley Ultra3000 Migration Guide

Rockwell Automation Publication 2198-RM003B-EN-P - November 2020 57
Chapter 4 Dimensions, Cables, and Wiring
In Figure 26, xxx is replaced by 030, 050, 100, 150, or 220 to represent the
Ultra3000 3, 5, 10, 15, and 22 kW drives respectively.
Figure 26 - 2098-DSD-HVxxx, 2098-DSD-HVxxxX, 2098-DSD-HVxxx-SE, 2098-DSD-HVxxx-DN,
2098-DSD-HVxxxX-DN Dimensions
225.8
(8.89)
A
C
B
B
D
I
H
242.2
(9.54)
C
B
B
Unit shown is the 2098-DSD-HV030.
Table 52 - Ultra3000 (400V) Dimensions in mm (in.) for 2098-DSD-HVxxx,
2098-DSD-HVxxxX, 2098-DSD-HVxxx-SE, 2098-DSD-HVxxx-DN, 2098-DSD-HVxxxX-DN
Ultra30040 Drives
(1)
Cat. No.
(1) The x represents the indexing (X) option. The -xx represents the Sercos interface (SE) or DeviceNet interface (DN) option.
Sercos interface is not available with the DeviceNet interface option.
A
mm (in.)
C
mm (in.)
B
mm (in.)
D
mm (in.)
H
mm (in.)
I
mm (in.)
2098-DSD-HV030x,
2098-DSD-HV030-xx, 2098-
DSD-HV050x,
2098-DSD-HV050-xx
138.7
5.46)
18.5
(0.73)
50.8
(2.0)
349.3
(13.75)
331.5
(13.05)
360.7
(14.2)
2098-DSD-HV100x,
2098-DSD-HV100-xx, 2098-
DSD-HV150x,
2098-DSD-HV150-xx
151.6
(5.97)
25
(0.99)
2098-DSD-HV220x,
2098-DSD-HV220-xx
203.2
(8.0)
25.4
(1.0)
76.2
(3.0)
380.4
(14.98)
362.6
14.26)
391.8
(15.43)
