Chapter 3 Control Component Definition and Maintenance
P3 – ISOLATOR
(T
o Isolator
Modules)
PIN NO. LABEL DESCRIPTION ONLY
1 ISOLATOR (+24V,1A) +24V,1A/com4
2 ISOL_COMM (com4) 0V/com4
3 EARTH EARTH
P4 – PWR (To
ACB)
PIN NO. LABEL DESCRIPTION ONLY
1 +24V_XIO (+24V,2A) +24V,2A/com3
2 XIO_COMM (com3) 0V/com3
3 +HECSPWR (+24V,1A) +24V,1A/com2
4 LCOMM (com2) 0V/com2
5 –HECSPWR (-24V,1A) -24V,1A/com2
6 +15V_PWR (+15V,1A) +15V,1A/com1
7 ACOMM (com1) 0V/com1
8 –15V_PWR (-15V,1A) -15V,1A/com1
9 +5V_PWR (+5V,5A) +5V,5A/com1
10 DGND (com1) 0V/com1
11 EARTH earth ground
