Appendix B PowerFlex 7000 Drive Spare Part Storage Requirements and Recommendations
Spare Parts Maintenance
Schedule
Use the following table to determine the appropriate action per the spare parts
maintenance schedule below.
Ch Charging This indicates that the component should be charged to maintain component integrity.
E Energizing This indicates that the component should be energized to maintain component integrity.
R
Recondition/
Reforming
This indicates that the component should be reconditioned/reformed to maintain
component integrity.
Re Replacement
This indicates that the component has reached its mean storage life, and should be
replaced.
Ro Rotating This indicates that the component should be rotated to maintain component integrity.
Component Type
Period Interval (Months)
3691215182124273033363942454851545760
Power Supplies
Pioneer/Cosel
power supply
——— E ———E———
E/R
(1)
——— E ———E
IGDPS ——— E ———E———
E/R
(1)
——— E ———E
IntelliVAC module ——— E ———E———
E/R
(1)
——— E ———E
Absopulse AC/DC Conv.——— E ———E———
E/R
(1)
——— E ———E
Absopulse DC/DC Conv.——— E ———E———
E/R
(1)
——— E ———E
1606 Power Supply ——— - ——— -———
E
(2)
——— — ———
E
(2)
UPS battery — Ch — Ch — Ch — Ch — Ch — Ch — Ch — Ch — Ch — Re
Control Equipment
and Boards
ACB ——— E ———E——— E ——— E ———E
Lithium battery for
DPM
——— — ———————Re ——— - ——— -
Power Components
SGCT ——— E ———E———
E/R
(1)
——— E ———E
SCR SPGDB ——— E ———E———
E/R
(1)
——— E ———E
SPS board ——— E ———E———
E/R
(1)
——— E ———E
Air-cooling system Cooling fans Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro
Additional DevicesSignal conditioner ——— — ——————— Re ——— — ————
Component Type
Period Interval (Months)
63 66 69 72 75 78 81 84 87 90 93 96 99 102 105 108 111 114 117 120
Power Supplies
Pioneer/Cosel
power supply
———
E/R
(1)
———E——— E ———
E/R
(1)
———E
IGDPS board — — —
E/R
(1)
———E——— E ———
E/R
(1)
———E
IntelliVAC module — — —
E/R
(1)
———E——— E ———
E/R
(1)
———E
Absopulse AC/DC Conv. — — —
E/R
(1)
———E——— E ———
E/R
(1)
———E
Absopulse DC/DC Conv. — — —
E/R
(1)
———E——— E ———
E/R
(1)
———E
1606 Power Supply — — —
E
(2)
——————— — ———
E
(2)
———
E
(2)
UPS battery — Ch — Ch — Ch — Ch — Ch — Ch — Ch — Ch — Ch — Re
Control equipment
and boards
ACB ——— E ———E——— E ——— E ———E
Lithium battery for
DPM
———Re ——— - ——— - ——— Re ————
Power Components
SGCT — — —
E/R
(1)
———E——— E ———
E/R
(1)
———E
SCR SPGDB — — —
E/R
(1)
———E——— E ———
E/R
(1)
———E
SPS board — — —
E/R
(1)
———E——— E ———
E/R
(1)
———E
Air-cooling system Cooling fans Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro Ro
Additional devicesSignal conditioner ———Re——————— — ——— Re————
(1) Recommended energizing item up for 1…2 hours every year of storage. If the item was stored for a longer time without energizing (longer than 3 years), then the reconditioning procedure
must be applied.
(2) With an average storage temperature of 25 °C (77 °F) the energizing procedure should be performed at least every five years, and at higher temperatures every three years.
