Rockwell Automation Publication 7000-UM202H-EN-P - November 2023 45
Chapter 2 Power Component Definition and Maintenance
Filter Capacitor Mounting Plate
Depending on your drive configuration, you may need to assemble or remove a
filter capacitor mounting plate. Oil-filled capacitors manufactured by Ducati
Energia and ICAR are no longer available. Replacement Shizuki capacitors are
available, but are not in all cases the same size and require additional
disassembly or assembly to install them in the drive.
If you are replacing a Ducati capacitor with a Shizuki capacitor, you must
remove the existing mounting plate. See Table 3
for details.
If you are replacing a ICAR capacitor with a Shizuki capacitor, you must install
a mounting plate. See Table 4
for details and Capacitor Mounting Plate
Assembly on page 46.
WARNING: Allow 5…10 minutes for motor capacitors to safely discharge voltage
prior to opening cabinet doors.
WARNING: The following fault codes may also indicate a non-operational
Motor Filter Capacitor (MFC):
F96 (Motor Overcurrent Fault)
F98 (Motor Neutral Overvoltage Fault)
F99 (Motor Flux Unbalance Fault)
F100 (Motor Current Unbalance Fault)
F103 (Motor Stall Fault)
F113 (DC Link Overcurrent Fault)
F114 (Ground Overcurrent Fault)
F115 (Neutral Resistor Overcurrent Fault)
F145 (Neutral Resistor Overload Fault)
Do not reset these faults until you have determined the root cause of the fault.
Operating a synchronous transfer system (specifically during the ‘Transfer to
Drive’ operation, also known as the de-sync operation) with a non-operational
MFC can lead to serious personal injury and/or property damage.
Table 3 - Select a Shizuki Capacitor when Replacing Ducati Capacitors
Original Ducati Capacitor Replacement Shizuki Capacitor
Instruction
Part Number Description Part Number Description
80026-488-03 6600V-400 kVAR, 75 Hz PN-680965
6600V-400KVAR 75 Hz
FL66C40EJXXR4A
Remove existing mounting plate.
80026-488-07 6600V-400 kVAR, 75 Hz PN-E089298
6600V-400KVAR 90 Hz
FL66C40EJXXR4B
No action required.
No mounting plate needed.
80026-488-08 6600V-400 kVAR, 75 Hz PN-E089299
6600V-500KVAR 90 Hz
FL66C50EJXXR4B
Remove existing mounting plate.
Table 4 - Select a Shizuki Capacitor when Replacing ICAR Capacitors
Original ICAR Capacitor Replacement Shizuki Capacitor
Instruction
Part Number Description Part Number Description
PN-326214
6600V-400 kVAR 90 Hz,
BIORIPHASO/TF 400/6.6/T
PN-E089298
6600V-400KVAR 90 Hz,
FL66C40EJXXR4B
See Capacitor Mounting Plate
Assembly on page 46.
PN-326211
6600V-500 kVAR 90 Hz,
BIORIPHASO/TF 500/6.6/T
PN-E089299
6600V-500KVAR 90 Hz,
FL66C50EJXXR4B
No action required.
No mounting plate needed.
