96 Rockwell Automation Publication 7000-UM202H-EN-P - November 2023
Chapter 2 Power Component Definition and Maintenance
Figure 87 - PowerCage Gasket Location (Heatpipe Model)
Replacing PowerCage Gaskets
The gaskets do not normally require replacement, but in the event that they
become damaged, you may have to replace them.
Remove Old Gasket Material
Remove as much material as possible by hand to leave an even, bondable
surface. Scrape off as much material as possible with a sharp knife, but avoid
scoring the PowerCage module. Clean away any loose pieces of gasket before
proceeding with the gasket installation.
Clean the PowerCage module with a general purpose household cleaner. Do
not spray onto the PowerCage module as this promotes electrical tracking.
Apply the cleaner to a paper towel and wipe the surface of the PowerCage
module where you will apply the gasket. Liberally spray the surface with
distilled water, then wipe dry with a clean paper towel.
Resistors
Gasket
PowerCage Housing
To Next Page
