Chapter 3 Control Component Definition and Maintenance
ACB-TP15 I2u Line current, CT2U
A
CB-TP16 I2w Line current, CT2W
ACB-TP17 Vzs2 Zero sequence generation line side, VZS2
ACB-TP18 Vn1 Line filter CAP neutral voltage for bridge #1, LFCN1
ACB-TP19 V2_pk AC over voltage detection for 2UVW
ACB-TP20 Vdcr1 Line side DCLINK voltage for bridge#1, VLDC1
ACB-TP21 Idc1 DCLINK current, HECSDC1
ACB-TP22 Vvws Line voltage synchronous feedback, VSBC
ACB-TP23 V3uv Line voltage feedback, 3UV
ACB-TP24 V3vw Line voltage feedback, 3VW
ACB-TP25 V3wu Line voltage feedback, 3WU
ACB-TP26 I3u Line current, CT3U
ACB-TP27 I3w Line current, CT3W
ACB-TP28 Vzs3 Zero sequence generation line side, VZS3
ACB-TP29 Vn2 Line filter CAP neutral voltage for bridge #2, LFCN2
ACB-TP30 V3_pk AC over voltage detection for 3UVW
ACB-TP31 Vdcr2 Line side DCLINK voltage for bridge#2, VLDC2
ACB-TP32 Idc2 DCLINK current, HECSDC2
ACB-TP33 Vwus Line voltage synchronous feedback, VSCA
ACB-TP34 V4uv Line voltage feedback,4UV
ACB-TP35 V4vw Line voltage feedback,4VW
ACB-TP36 V4wu Line voltage feedback,4WU
ACB-TP37 I4u Line current,CT4U
ACB-TP38 I4w Line current, CT4W
ACB-TP39 Vzs4 Zero sequence generation line side,VZS4 (spare one)
ACB-TP40 Vnn CMC neutral voltage, VNN
ACB-TP41 Inn CMC neutral current, INN
ACB-TP42 Ignd Ground fault current, GFCT
ACB-TP43 Vspr Spare channel for inputs
ACB-TP44 Vmtrp Motor over voltage detection set point
ACB-TP45 A+ Encoder A+ input
ACB-TP46 B+ Encoder B+ input
ACB-TP47 Z+ Encoder Z+ input
ACB-TP48 A- Encoder A- input
ACB-TP49 B- Encoder B- input
ACB-TP50 Z- Encoder Z- input
ACB-TP51 CP1 Control power monitoring for channel 1
ACB-TP52 CP2 Control power monitoring for channel 2
ACB-TP53 CP3 Control power monitoring for channel 3
ACB-TP54 CP4 Control power monitoring for channel 4
ACB-TP55 Vltrp AC over voltage detection set point for 2UVW & 3UVW
ACB-TP56 AGND Analog ground
ACB-TP57 AGND Analog ground
ACB-TP58 AGND Analog ground
ACB-TP59 AGND Analog ground
ACB-TP60 +5V +5V DC power supply
ACB-TP61 +15V +15V DC power supply
ACB-TP62 -15V -15V DC power supply
ACB-TP63 +24V +24V DC power supply
ACB-TP64 -24V -24V DC power supply
ACB-TP65 24VCOM +/- 24V common
Table 13 - Test Points on Analog Control Board (Continued)
Test points Name Description
